Dynamic Simulation

Setting New Standards for Rigor, Robustness and Ease
of Use

AVEVA Dynamic Simulation is a comprehensive, dynamic process simulator that enables users to meet and beat the dynamic challenges of designing, commissioning, controlling, and operating a modern process plant safely, reliably, and profitably.

AVEVA Dynamic Simulation is available via the cloud or via traditional on-premise access, as well as runtime licenses for use in operator training simulators.

AVEVA Dynamic Simulation

State-of-the-art, field-proven dynamic simulation for modern process plants.

AVEVA Dynamic
Simulation Power

An advanced power plant modeling and dynamic simulation environment for use throughout a power plant’s life cycle.

Engineering Services

An unparalleled combination of industry experience, process simulation knowledge and best-in-class technology.

Operator Training

High fidelity dynamic simulations of the actual process plant connected with 3rd Party control systems as a plaftorm for control checkout and operator training.

AVEVA Dynamic Simulation for Process Plants

AVEVA Dynamic Simulation helps engineers save capital cost, decrease time to market, improve safety, and increase plant availability.

Improve Performance and Profitability
By assisting in process design, controls checkout and control system design, AVEVA Dynamic Simulation enables process yield improvement and reduction of capital investment costs.

First Principles Equipment Models
First principles models, including rigorous thermodynamic and fluid flow calculations, bring a superior level of robustness and accuracy to dynamic process simulation.

Import existing PRO/II™ Simulations
Translate a steady-state AVEVA PRO/II Simulation into a running dynamic simulation to eliminate tedious data re-entry, and preserve the thermodynamic methods that you trust.

Cloud Access Available
AVEVA Connect makes AVEVA Dynamic Simulation available via a pure SaaS model in addition to the traditional on-premise access method.

AVEVA Dynamic Simulation Power

High fidelity AVEVA Dynamic Simulation for the Power industry. Create flexible, dynamic simulation models that can be combined with a DCS simulation for engineering validation, control system checkout, and operator training.

Simulate power plant designs:

• Conventional Drum-unit Gas, Oil, Biomass or Pulverized Coal-fired Power Plants
• Once-through Supercritical Gas, Oil, Biomass or Pulverized Coal-fired Power Plants
• Circulating Fluidized Bed-unit Gas, Oil, Biomass, or Pulverized Coal-fired Power Plants
• Gas Turbine and Combined Cycle Plants

Combine the specialized models of AVEVA Dynamic Simulation Power with the AVEVA Dynamic Simulation product to create integrated systems unrivaled in the industry. Simulate any of the following complex plant designs:

• Integrated Gasification Combined Cycle (IGCC)
• Combined LNG Terminal / Power Plant
• Refinery Steam Generation and Distribution

Engineering Services for Dynamic Simulation

AVEVA’s dynamic simulation services combine industry experience, process simulation knowledge, and best-in-class technology, enabling our customers in the Upstream, Hydrocarbon and Power industries to realize significant benefits in capital costs, time-to-market, safety, and availability. Our engineers can augment your own team’s expertise on a wide range of dynamic analysis applications.

• Compressor Surge Analysis
• Compressor Startup Analysis
• Column Control Strategy Selection
• Column Relief Load Analysis
• Flare System Studies
• Cryogenic Depressuring for Minimum Metal Temperature Specification

• Hydroprocessor Depressuring for Feed / Effluent Heat Exchange Design
• Integrated Pipeline / Topsides Modeling
• Cryogenic Exchanger Stress Analysis
• Boiler Draft Studies for FGD Retrofits
• Refinery Steam System Analysis
• …and many more!

Operator Training

Plant models in AVEVA Dynamic Simulation are the core of AVEVA Operator Training Simulators (OTS) for any industry – from Food & Beverage to Upstream Oil & Gas. Over 1200 plants worldwide have used custom or generic dynamic models combined with control system emulators in OTS to perform control system checkout, develop and test first time startup procedures, train new operators and improve operator performance.

High Fidelity Plant Models

The high-fidelity dynamic simulation plant model reflects the operations and control responses of the actual plant. AVEVA Dynamic Simulation’s first principles models, including rigorous thermodynamic and fluid flow calculations, bring a superior level of robustness and accuracy to dynamic process simulation at your plant.

Connect with DCS and PLC Control Systems

Modern, open software standards interface with other important plant applications, such as DCS and PLC control system emulators, to drive operator training systems with a rigorous simulation foundation. AVEVA Dynamic Simulation provides an open API to connect any third-party simulation system.

Cloud Access and Flexible Licensing

AVEVA Connect makes AVEVA Dynamic Simulation fully scalable and accessible from anywhere. Cloud OTS enables widespread use of dynamic, high-fidelity simulation models.

Full development licenses allow simulator customization. Runtime licenses provide the full power of the operating model but restrict modification of the simulation database that defines it. This reduces the deployment cost of OTS.
